Description
The CE R32 6 kW Monoblock Heat Pump delivers heating, cooling and domestic hot water in one compact, easy‑to‑install unit. All components are factory‑assembled, so no refrigerant piping or outdoor module is required—just connect to your hydronic loop (and ductwork if desired).
Key Features
All‑in‑One Monoblock: Simplifies installation; no indoor/outdoor split.
Hyper Performance: Heats reliably down to very low outdoor temperatures; cools effectively in peak summer heat.
3‑in‑1 Function: Provides space heating, space cooling and domestic hot water.
Eco‑Friendly R32 Refrigerant: Lowers global‑warming potential and boosts efficiency.
Duct‑Ready: Integrates with existing ductwork for uniform air distribution.
Smart Control: Intuitive onboard interface plus Wi‑Fi/APP connectivity for remote scheduling and monitoring.
Low Maintenance: Rugged components, self‑diagnostics and easy access panels ensure years of trouble‑free operation.
The CE R32 6KW Heating Cooling DHW Heat Pump Monoblock is suitable for a wide range of applications, including residential homes, small commercial buildings, and other facilities. Its compact size and versatile functionality make it an ideal choice for various settings, providing a comprehensive climate control solution in a single unit. Whether you need efficient heating, cooling, or hot water, this heat pump meets diverse needs with high performance and reliability.
parameter
| QBKFXFC-006SRI | |||
| Heating Capacity (A7W35) | 6 kW | COP | 4.42 |
| Cooling capacity (A35W7) | 5 kW | EER | 2.85 |
| DHW (A20W55) | 8 kW | COP | 4.3 |
| Compressor | Panasonic | ERP(35℃) | A +++ |
| Refrigerant Type | R32 | Max Input Power | 3.8 |
| Power Supply | 220-240V～ / 50Hz | Max Current （A） | 16 |
| Water flow (m³/h) | 1.38 | Water Port Size | DN25 |
| Pressure Loss（kPa） | 25 | Noise (dB（A)) | ≤54 |
| Dimension (W×D×H) | 1075*480*805 mm | Packing Dimension (W×D×H) | 1190*560*945 mm |
| N.W.( kg) | 80 | G.W.( kg) | 98 |
| Note: Due to product improvement, above datas are subject to change without prior notice, please take the name plate as standard. | |||
Details
Heating&Cooling&DHW 3 In 1
Cooling in summer, heating in winter, optional wind panel, floor heating, domestic hot water, etc. at the end,
convenient and flexible R32 full DC inverter EVI heat pump for higher efficient house heating/cooling and
domestic hot water.
High Efficiency A+++ Energy Level
Targeting the European market, 3VF+ Series Air to Water Heat Pump is specially developed with the most
cutting-edge heat pump technology and modern design to meet stringent requirements for efficiency, stability
and quietness. Not only does 3VF+ series use R32 Refrigerant and full DC Inverter EVI technology, but also be
rated with A+++ energy label. With top energy rating A+++ , the unit is currently most energy efficient and
can greatly reduce energy bills for customers.
High Efficiency Full DC Inverter Compressor
Adopt DC inverter compressor and DC brushless fan motor, which can realize 20%-120% stepless capacity
adjustment. During operation, the speed of the compressor and fan can be automatically and intelligently
adjusted according to the actual load demand of the user, so as to reduce the energy consumption of the
compressor and fan , so that the unit operates at the optimal level and achieves the energy saving purpose
of on-demand output
R32 refrigerant, energy saving and environmental protection
R32 contributes greatly to the environment protection since R32 has a low GWP of 675 which is just 32% of R410A.
In the same heat pump system, with lower liquid density, the charge amount of R32 is less than that of R410A,
which brings in higher economic efficiency. The heat needed to evaporate R32 is greater than that of R410A so
that the required mass flow rate per unit is smaller and the COP is higher. We not only take care of your family
but also contribute to protecting the earth.
40dB(A) Quiet Running
Thanks to the unique soundproof internal structure, the sound pressure of this type of Air to Water Heat Pump
is kept to as low as 40dB(A) at 1 meter distance (Min. Flow).
Stable Running at -35°C Ambient Temperature
Under low ambient Temperature, the performance of normal heat pumps will be limited. First, the heating ability,
the lower the ambient temperature, the weaker the heating ability. Second, reliability, low temperature
environment will affect the stability of the machine and operation reliability. Third, the operating width and safety
range will affect the performance of the heat pump. Thanks to the unique Inverter EVI technology, 3VF+ can operate
efficiently at -35°C, maintain high COP and reliable stability.
Controller with WIFI to realize APP remote setting. Convenient for installation and maintenance.
Independent intelligent remote control, online self-diagnosis function
- Remotely view the temperature and water level of the water tank and other parameter curve records and query,
and control the water level and water temperature at the same time;
- Remote control of pipeline circulation, return water, antifreeze, defrost, etc.;
- Remotely monitor the working status, current, voltage, protection status and working mode of the pump set;
- Remotely switch the control mode of the water pump, and remotely/manually/automatically control the start
and stop of the pump group;
- Fault information early warning and display, support various monitoring information, control information, alarm
information, operation information storage and historical record query.
Automatic defrost mode + anti-secondary long ice technology
The outdoor unit adopts outdoor temperature sensor and heat exchanger temperature sensor to perform
variable-parameter defrosting and accurately grasp the defrosting timing, which effectively solves the problem
of "no defrosting when there is frost, but defrosting without frost", and the amount of frost per unit time is
significantly reduced. Only 1/3 of the normal defrost mode.
