Description
The 150L Cylinder In-built Split Unit Air To Water Heat Pump is a highly efficient and versatile solution designed to meet the heating and cooling needs of modern homes. This advanced system combines the functionality of an air-to-water heat pump with the convenience of a 150-liter in-built cylinder, ensuring a reliable supply of hot water, heating, and cooling throughout the year. Its split unit design allows for flexible installation options, making it an ideal choice for residential spaces looking to optimize comfort and energy efficiency.
This split unit air-to-water heat pump is engineered to provide consistent and energy-efficient heating and cooling for your home. By transferring heat between the air and water, the system efficiently regulates indoor temperatures, keeping your home warm during the winter and cool during the summer. The in-built 150L cylinder ensures that you always have a ready supply of hot water, making this system a comprehensive solution for all your domestic heating, cooling, and hot water needs.
If you’ve experienced issues with a heat pump AC not cooling effectively, this system is designed to address those concerns. The advanced technology behind this split unit air-to-water heat pump ensures reliable and efficient cooling, even in the hottest weather. With its high-performance components, the system quickly cools your home to the desired temperature, providing relief from the heat and maintaining a comfortable indoor environment.
This system doubles as a heat pump air conditioning and heating system, offering seamless integration for all your climate control needs. Whether you require cooling in the summer or heating in the winter, the system adjusts effortlessly to maintain the ideal indoor temperature. The dual functionality eliminates the need for separate heating and cooling units, saving space and reducing installation complexity. The 150L in-built cylinder further enhances the system’s efficiency, ensuring that hot water is always available when needed.
The 150L Cylinder In-built Split Unit Air To Water Heat Pump functions as both a heat pump air conditioner and heater, providing year-round comfort with a single system. In cooling mode, it effectively lowers indoor temperatures, while in heating mode, it delivers consistent warmth throughout your home. The system’s split unit design allows for flexible installation, with the indoor and outdoor units working together to optimize performance and energy use. This versatility makes it an excellent choice for homeowners looking to streamline their climate control systems.
For homeowners seeking a reliable and efficient climate control solution, this heat pump air conditioner heater offers unmatched performance. Its ability to maintain consistent temperatures throughout the year, combined with the convenience of an in-built hot water cylinder, makes it a comprehensive solution for residential spaces. The system is designed to operate quietly and efficiently, minimizing disruption while maximizing comfort.
Energy efficiency is a key feature of the 150L Cylinder In-built Split Unit Air To Water Heat Pump. By using ambient air as a primary heat source, the system reduces reliance on electricity, resulting in lower energy bills and a reduced carbon footprint. The integrated 150L cylinder stores hot water efficiently, ensuring that energy is not wasted. This combination of heating, cooling, and hot water supply in one unit makes the system a cost-effective and environmentally friendly option for homeowners.
The split unit design of this air-to-water heat pump allows for easy installation in a variety of residential settings. The system’s components are designed for flexible placement, accommodating different home layouts and preferences. The user-friendly control panel offers intuitive operation, allowing homeowners to easily adjust temperatures and settings to suit their needs. With programmable options and smart features, the system offers convenience and customization, enhancing the overall user experience.
Parameter
| HP22ST | |||
| Heating Capacity (A7W35) | 17.6 kW | COP | 4.48WW |
| Cooling capacity (A35W7) | 13.8 kW | COP | 2.83W/W |
| DHW (A20W15-55) | 21.5KW | Water Tank | 200L |
| Compressor | Panasonic | ERP(35℃) | A +++ |
| Refrigerant Type | R32 | Rated Input Power/Current | 6.0KW/9.1A |
| Power Supply | 380V/50Hz/3PH | Max. Input Power | 12KW/18.18A |
| Water Flow (m³/h) | ≥2.58m³/h | Water Proof Class | IPx4 |
| Max Pressure | 4.2Mpa | Noise (dB（A)) | ≤48dB(A) |
| Packing Dimension (W×D×H)Outdoor unit | 1160*520*1500(mm) | Packing Dimension (W×D×H) indoor unit | 620*720*1830(mm) |
| Dimension (W×D×H) Outdoor unit | 1040*445*1350 | Dimension (W×D×H) indoor unit | / |
| N.W.( kg) Outdoor unit | 65 | N.W.( kg) indoor unit | 195 |
Details
Heating&Cooling&DHW 3 In 1
Cooling in summer, heating in winter, optional wind panel, floor heating, domestic hot water, etc. at the end,
convenient and flexible R32 full DC inverter EVI heat pump for higher efficient house heating/cooling and domestic hot water.
High Efficiency A+++ Energy Level
Targeting the European market, 3VF+ Series Air to Water Heat Pump is specially developed with the most
cutting-edge heat pump technology and modern design to meet stringent requirements for efficiency,
stability and quietness. Not only does 3VF+ series use R32 Refrigerant and full DC Inverter EVI technology,
but also be rated with A+++ energy label. With top energy rating A+++ , the unit is currently most energy
efficient and can greatly reduce energy bills for customers.
High Efficiency Full DC Inverter Compressor
Adopt DC inverter compressor and DC brushless fan motor, which can realize 20%-120% stepless capacity adjustment.
During operation, the speed of the compressor and fan can be automatically and intelligently adjusted according to the
actual load demand of the user, so as to reduce the energy consumption of the compressor and fan , so that the unit
operates at the optimal level and achieves the energy saving purpose of on-demand output.
Automatic defrost mode + anti-secondary long ice technology
The outdoor unit adopts outdoor temperature sensor and heat exchanger temperature sensor to perform variable-parameter defrosting and accurately grasp the defrosting timing,
which effectively solves the problem of "no defrosting when there is frost, but defrosting without frost", and the amount of frost per unit time is significantly reduced. Only 1/3 of the
normal defrost mode.
